Description
| PART NO. | THREAD E | HOSE BORE | DIMENSIONS | |||
|---|---|---|---|---|---|---|
| DN | DASH | A | C | S1 | ||
| 17811-04-04 | 7/16"X20 | 6 | 04 | 25.5 | 12.7 | 12 |
| 17811-05-05 | 1/2"X20 | 8 | 05 | 27 | 14.2 | 14 |
| 17811-06-06 | 5/8"X18 | 10 | 06 | 28.5 | 15.7 | 17 |
| 17811-08-08 | 3/4"16 | 12 | 08 | 34 | 19 | 22 |
| 17811-10-10 | 7/8"X14 | 16 | 10 | 38.5 | 22.4 | 24 |
| 17811-12-12 | 1.1/16"X14 | 20 | 12 | 43.5 | 25.4 | 30 |
| Note: 1.For ues with braided hoses. 2.If use with spiral hoses,hose fitting series number is 17812-XX-XX. | ||||||
